Long-life and high power halogen heater provides quick and accurate measurement.
The temperature can be changed from 50 degrees to 200 degree Celsius.
You can check sample status from window while measurement.
The measure results can be transferred by USB cable.
If connect with PC by USB, needs USB driver.
MOC63u has large pwn. (95mm diameter)
It can provide quick and accurate measurement to spread sample in thin layer on the pan.
Send balance data to Excel or other Windows applications without installing additional data communication software. By combining standard Auto print functions with typical spreadsheet functions, even difficult applications can be easily automated.
You can create graphs easily with WindowsDirect and Excel.
Features easy-to-operate software and keypad layout. In addition, an automatic starting mode saves measurement time, increasing your work efficiency. Operation simply requires ‘putting material on the pan and shutting the cover’. Internal memory can save 10 measurement conditions and 100 results. Various measurement modes provide extra support.
Automatic ending mode
Automatically ends measurement when moisture loss over the previous 30 seconds becomes smaller than specified percentage.
Automatically ends measurement when the specified amount of time has elapsed.
Rapid drying mode
First dries with the highest temperature for the specified period, then shifts to the specified temperature, shortening measurement time.
Gently heats samples that might solidify at the surface or samples that reduce under high temperature.
Allows step-by-step change in drying conditions. This feature is useful when measuring samples that contain a large amount of water.
Automatic starting modeStarts measurement immediately after closing the lid. It saves time in repeat measurements.
Capacity | 60g 0.02g |
---|---|
Dimension | (W×D×H) mm 202 × 336 × 157 |
Measurement conditions data memory | 10 |
Interface | RS-232C (9-pin connector) I/O port USB port |
Timer setting | 1-120 minutes or continuous (max 12 hours) |
Measurement modes | Standard (Easy start/Automatic end/Timed end) Rapid drying (Easy start/Automatic end/Timed end) Slow drying (Easy start/Automatic end/Timed end) Step drying (Easy start/Automatic end/Timed end) |
Operational temperature and humidity range | 5 to 40°C, 85%RH or lower |
Weight | 4kg |
Pan Size | 95mm dia |
Minimum readability | 0.001g 0.01/0.1% (Selectable) |
Display | LCD with backlight |
Setting | (There is a time restriction when exceeding 180°C.) |
Temperature range | 50-200°C (1°C increments) |
Power | 400W |
Drying Heater | Straight type halogen heater |
Repeatability | 0.15% (2g) 0.05% (5g) 0.02% (10g) |
Data memory | 100 |
Weighing capacity | 60 g |
---|---|
Minimum indication | 0.001 g / 0.01% |
External output | RS-232C interface USB interface DATA I/O interface |
